MAHINDRA 245 DI ORCHARD TRACTOR SUPPLY
.jpeg)
| Engine HP | 24 HP |
| PTO HP | 20.4 HP |
| Driver Type | 2WD |
| Forward Gears | 6 |
| Reverse Gears | 2 |
| Brake Type | Oil Immersed |
| Price | ₹ 3.60 - 4.00 lakh |
Price: 403000
PTO HP : 20 HP
Forward Gears : 6
Reverse Gears : 2
Steering Type : Power Steering
Brakes : Oil Immersed
Lift Capacity : 1000 kg
FEATURES
Mahindra 245 DI Orchard is equipped with a 2-cylinder diesel engine delivering a total output of 24 HP. A 6-spline type PTO helps to deliver an PTO HP output of 20 HP, this PTO has an RPM range of 540 RPM. This tractor has a wheel setup of 5 X 15 inches in the front and 9.5 X 24 inches in the rear. This setup helps to carry out activities in different types of terrains. In order to deliver the maximum power through its transmission which is of Combination of Combi constant and sliding mesh type. This transmission is attached through a Single Friction Plate.
| ENGINE | |
|---|---|
| HP Category | 24 HP |
| Engine Rated RPM | 1800 RPM |
| No of Cylinder | 2 |
| Air Filter | Dry type, Dual element with dust unloader |
| Cooling System | Water Cooled |
| TRANSMISSION (GEARBOX) | |
|---|---|
| Clutch type | Single Friction Plate |
| Transmission type | Combi constant and sliding mesh |
| Speed min-max | 2.2 – 23.3 kmph |
| Reverse speed min - max | 2.2 – 8.7 kmph |
| Forward Gears | 6 |
| Reverse Gears | 2 |
| BRAKES | |
|---|---|
| Brake Type | Oil Immersed |
| STEERING | |
|---|---|
| Steering Type | Power Steering |
| Steering Adjustment | NO |
| POWER TAKE OFF | |
|---|---|
| PTO type | 6 Spline |
| PTO RPM | 540 |
| PTO POWER | 20.4 HP |
| FUEL CAPACITY | |
|---|---|
| Fuel Tank Capacity | 25 litres |
| DIMENSION AND WEIGHT | 2WD |
|---|---|
| Weight | 1440 KG |
| Wheelbase | 1550 MM |
| Overall Length | 2900 MM |
| Tractor width | 1092 MM |
| Ground Clearance | 220 MM |
| LIFTING CAPACITY (HYDRAULICS) | |
|---|---|
| Lift capacity in kg | 1000 kg |
| 3 Point linkage | Category - I |
| Hydraulic Controls | PCDC |
| TYRE SIZE | |
|---|---|
| Front | 5 X 15 |
| Rear | 9.5 x 24 |
| ADDITIONAL FEATURES | |
|---|---|
| Drive type | 2WD |
| WARRANTY | |
|---|---|
| Warranty | 2000 hr/2 year |
Brand: Mahindra
Clutch Type: Single Clutch (Diapharam Type) with Mechanical Actuation
Engine Power: 24 hp
Model Number: 245 DI Orchard
Engine - Type: 4 Stroke, Direct injection, Diesel engine.
Number of Gears: 6 Forward & 2 Reverse
Lifting Capacity: 1000 kg At Lower Link Ends
Engine - Rated Rpm: 1800
Tyres - Rear Tyret: 9.5 x 24
Transmission - Type: Sliding Mesh & Range gears in Constant Mesh
Tyres - Front Tyret: 5.00 x 15
Brakers - Brake type: Oil Immersed Brakes
Engine - Air Cleaner: Dry type,Dual element with dust unloader
Hydraulics - Linkage: 3 point linkage Category-I suitable for Category-II type implement pins.
Engine - Cooling System: Water Cooled
Hydraulics - Hydraulics: Live Hydraulics A) Position control:To hold lower links at any desired height. B) Automatic draft control:To maintain uniform draft
Steering - Steering type: Hydrostatic Power Steering
Electricals - Electricals: 12 volt, 75 Ah.Battery,Starter motor & Alternator
Engine - No. of Cylinders: 2
PTO - PTO rpm@ Engine rpm: 540 @ 1800
Weights & Dimensions - Wheel Base: 1550 mm
Weights & Dimensions - Wheel track: Front 970 mm Rear 840 mm
Weights & Dimensions - Weight of Tractor: 1440 kg
Weights & Dimensions - Min.ground Clearance: 220 mm
Weights & Dimensions - Fuel tank capacity litre: 25
Weights & Dimensions - O.A.Length x Width x Height: 2900mm x 1092 mm x 1340 mm at steering wheel
Gear Speeds (Km/hr) With 5.00 x 15 front & 9.5 x 24 rear type - Forward: 2.2 to 23.3
Gear Speeds (Km/hr) With 5.00 x 15 front & 9.5 x 24 rear type - Reverse: 2.2 & 8.7
