SWARAJ 855 FE

Swaraj 855 FE is a 37.28 - 41.01 kW (50-55hp) category tractor with 3-cylinder water-cooled engine. An iconic tractor designed to deliver pure power, this tractor is designed for tough field operations & hard soil operations. It comes equipped with host of features like direction control valve, multi speed forward & reverse PTO, power steering, dual clutch etc. It is suitable for applications like M B plough, straw making machine, rotavator, genset compressor and combine

At a Glance

No. Of Cylinder : 3

Power Category : 37.28-41.01 kW (50-55 HP)

Engine : 3308 cm3

Brakes : OIB

PTO r/min : 540 r/min

SPECIFICATION

Engine

Model: RB-33 TR
Power: 37.28 - 41.01 kW (50-55 HP)
Type: 4 - Stroke, Direct Injection, Diesel Engine
No. of Cylinders: 3
Bore and Stroke: 110 X 116 mm
Displacement: 3307 cm3
Rated Engine Speed: 2000 r/min
Air Cleaner: 3- Stage Oil Bath Type
Cooling System: Water Cooled with No loss tank. Oil Cooler for engine oil

Clutch

Clutch Standard: Single dry disc friction plate - 305 mm dia.
Clutch Optional: Dual Clutch

Gear Speeds

No. of Gears: 8 Forward, 2 Reverse speeds
Forward: 3.1 to 30.9
Reverse: 2.6 to 12.9

PTO

PTO Speed: Standard 1000 r/min
PTO Speed: Optional 540 r/min, CR-PTO with Multi speeds

Brakes

Brake type: Standard Dry Disc type Brakes
Brake type: Optional Oil Immersed Brakes

Steering

Standard: Mechanical Steering with Heavy Duty single drop arm for better maneuverability & comfort to operator.
Optional: Power Steering

Hydraulics

Live Hydraulics: "A) Position control: To hold lower links at any desired height. B) Automatic draft control :To maintain uniform depth c) Mix Control : For optimum field output
Lifting Capacity: 1700 kg at lower link ends.
Linkage: 3 point linkage suitable for Category-I&II type implement pins.
